Advantages
The 15-06 diesel backhoe loader is a compact, multifunctional piece of construction equipment that integrates both loading and excavating capabilities. Powered by a genuine Yanmar diesel engine, it delivers stable, reliable performance and operates seamlessly in off-grid environments, supporting continuous, all-day operation.
Featuring an integrated front-loader and rear-excavator design, this single machine combines the full functionality of a compact loader and a mini-excavator, eliminating the need to purchase two separate units; a single operator can independently handle the entire earthmoving workflow. Its compact dimensions, lightweight build, and agile turning radius allow it to navigate narrow passageways with ease.
The machine is equipped with a dual-speed drive system: low speed is ideal for precision excavation and loading tasks, while high speed facilitates rapid relocation between factory sites, orchards, and construction zones, saving the hassle of trailer transport. It rides on wide, wear-resistant rubber tires that perform well on various surfaces—including dirt roads, lawns, and concrete—without damaging the ground, ensuring excellent mobility.
The hydraulic system is fine-tuned for specific operating conditions, with independent pressure settings for the loading and excavating circuits; this ensures responsive hydraulics and smooth, fluid operation cycles without sticking. The excavator boom supports a wide range of lateral rotation, allowing for trenching and soil clearing without the need to frequently reposition the machine. The operator station features an ergonomic layout with intuitively placed controls and responsive handling, enabling even novices to master the machine quickly. Built with a reinforced, thickened frame and neatly routed, high-integrity hydraulic lines, the machine is designed for durability and reliability, minimizing the risk of oil leaks or breakdowns during prolonged outdoor use.


Backhoe-Loader Combo: Dual-Function Efficiency and Cost Savings
This single machine combines the capabilities of a loader and a compact excavator, eliminating the need to purchase two separate units. A single operator can handle excavation, backfilling, and material loading/unloading, significantly reducing equipment acquisition and labor costs.
Compact and Agile: Easy Access to Tight Spaces
With a narrow profile and a tight turning radius, the machine easily navigates rural courtyards, greenhouses, narrow residential lanes, and landscaping areas. It fits through standard residential gates, solving the problem of large equipment being unable to access the site.
Two-Speed Travel & Rapid Hydraulics: High Operational Efficiency
Low-speed mode ensures precision, while high-speed mode allows for quick repositioning. The hydraulic cycle takes just 4–7 seconds, enabling rapid digging and loading; this replaces multiple manual laborers and drastically shortens project timelines.
Dual-Pressure Hydraulic System: Adaptable to Various Conditions
Independent hydraulic pressure settings for loading and excavating ensure powerful scooping and smooth digging. The boom offers a wide 170° rotation range, allowing for extensive trenching operations without the need to frequently reposition the machine.
Simple Maintenance & High Parts Compatibility
Engine and hydraulic components are widely available on the market, and maintenance is straightforward—requiring only routine oil and filter changes. The wear-resistant rubber tires are built for durability, making the machine suitable for diverse terrains, from farmland to construction sites.
Residential Property & Municipal Maintenance
Landscaping upgrades, trenching for stormwater drainage, road surface repairs, construction debris removal, and excavation for ornamental ponds.
Small-Scale Construction & Outdoor Projects
Rural road repairs, small-scale infrastructure earthworks, land clearing, and farm site renovations; capable of all-day operation without grid power.
Scenic Area & Farmstead Maintenance
Excavation for landscaping features, walkway maintenance, and debris transport; compact size prevents damage to greenery and paved surfaces.
Agriculture, Forestry, Orchards & Greenhouses
Digging trenches for orchard fertilization, hole digging for sapling planting, greenhouse soil tilling, transporting organic farm manure, and land clearing on hilly terrain; fuel-powered models ensure uninterrupted operation in the field.
Rural Residential & Courtyard Projects
Excavation for small courtyard foundations, digging pits for septic tanks, backfilling and leveling, short-distance loading/unloading of sand, gravel, and cement, and slope trimming.
|
Overall dimension (LWH) |
3400 * 1200 * 2175 mm |
|
Total weight |
1500 kg |
|
Loading bucket capacity |
0.3m³ |
|
Max. Lifting height |
2520mm |
|
Max. Dump height |
1738 mm |
|
Max. Dump distance |
700 mm |
|
Rated load capacity |
500kg |
|
Turning radius |
3100 mm |
|
Speed (high) |
20km/h |
|
Speed (low) |
8km/h |
|
Min. Ground clearance |
200 mm |
|
Wheel tread |
1130 mm |
|
Hydraulic working pressure (loader) |
20MPA |
|
Hydraulic working pressure (backhoe) |
15MPA |
|
Engine Model |
Yanmar 3TNV74F-SPSY |
|
Rated Power |
11.2KW |
|
Rated Speed |
2400rpm |
|
Max digging depth |
1580mm |
|
Max digging radius |
2670mm |
|
Max digging height |
2780mm |
|
Backhoe bucket capacity |
0.03m³ |
|
Digging arm rotation angle |
170° |
|
Tire size |
23*8.5-12 |
|
Full cycle operation time |
4-7s |
Q1: Can excavating and loading operations be performed simultaneously?
A1: No, they cannot be used at the same time; only the front bucket or the rear excavator arm can be operated individually. Switching between them is simple, and sequential operation fully meets operational needs.
Q2: Can the machine be fitted with attachments like a hydraulic breaker or a timber grapple?
A2: The rear excavator mount supports optional attachments such as hydraulic breakers, augers, and timber grapples, enabling functions like concrete breaking, tree-planting hole drilling, and material handling.
Q3: Is it difficult to start the machine in the field where there is no power supply?
A3: It runs entirely on diesel power—no charging required. It features one-touch electric starting and an integrated fuel tank; a full tank allows for continuous all-day operation in the field, independent of external power sources.
Q4: Will driving on soft or hard ground damage the surface?
A4: Equipped with wide rubber tires featuring a herringbone tread pattern, the machine minimizes damage to concrete surfaces and lawns, prevents slipping or sinking in soft farmland, and offers excellent mobility across various terrains.
